材質(zhì):銅
編號 |
螺栓孔直徑 |
尺寸(mm) |
電纜 |
|||
d2φ |
dφ |
Dφ |
L1 |
L |
||
SC1.5-5 |
5.2 |
1.8 |
3.7 |
5 |
16 |
1.5 |
SC2.5-4 |
4.2 |
2.4 |
4.0 |
7 |
18 |
2.5 |
SC2.5-5 |
5.2 |
20 |
||||
SC4-5 |
5.2 |
3.1 |
4.8 |
7 |
20 |
4 |
SC4-6 |
6.5 |
|||||
SC6-5 |
5.2 |
3.8 |
5.5 |
9 |
24 |
6 |
SC6-6 |
6.5 |
|||||
SC10-6 |
6.5 |
5 |
6.5 |
9 |
26 |
10 |
SC10-8 |
8.4 |
|||||
SC16-6 |
6.5 |
5.7 |
7.5 |
11 |
30 |
16 |
SC16-8 |
8.4 |
|||||
SC25-6 |
6.5 |
7.2 |
9 |
13 |
35 |
25 |
SC25-8 |
8.4 |
|||||
SC35-8 |
8.4 |
8.5 |
10.8 |
13.5 |
38 |
35 |
SC35-10 |
10.5 |
|||||
SC50-8 |
8.4 |
9.8 |
12.5 |
16 |
44 |
50 |
SC50-10 |
10.5 |
|||||
SC70-10 |
10.5 |
11.5 |
14.5 |
18 |
51 |
70 |
SC70-12 |
13.0 |
|||||
SC95-10 |
10.5 |
13.7 |
17 |
22 |
57 |
95 |
SC95-12 |
13.0 |
|||||
SC120-12 |
13 |
15 |
19 |
24 |
64 |
120 |
SC120-16 |
17 |
|||||
SC150-12 |
13 |
16.7 |
21 |
26 |
71 |
150 |
SC150-16 |
17 |
18.5 |
23 |
30 |
79 |
185 |
SC185-16 |
17 |
21 |
26 |
38 |
93 |
240 |
SC240-16 |
17 |
|||||
SC240-20 |
21 |
24.5 |
30 |
42 |
103 |
300 |
SC300-16 |
17 |
|||||
SC300-20 |
21 |
27 |
34 |
42 |
113 |
400 |
SC400-16 |
17 |
|||||
SC400-20 |
21 |
|||||
SC500-16 |
17 |
30 |
38 |
48 |
123 |
500 |
SC500-16 |
21 |
